introduce
attic-type shelf system, usually use medium-sized shelf-type shelf or heavy-duty shelf-type shelf as the main support plus floor slab (decide which shelf to choose according to the total load weight of the shelf unit), cold-rolled steel floor slab, pattern steel are usually used for floor slab floor or steel grille floor.
attic racking system is to build an intermediate attic on the existing work site or shelf to increase storage space. it can be used as a second or third floor attic. it is appropriate to access some light foam and small and medium-sized goods. it is suitable for many varieties or large batches. many kinds of small batches of goods, manual access to goods. the goods are usually sent to the second and third floors by forklifts, hydraulic lifting tables or freight elevators, and then sent to a certain location by light trucks or hydraulic pallet trucks.
in recent years, cold-rolled steel floor slabs have been used more frequently. it has the advantages of strong bearing capacity, good integrity, good bearing uniformity, high precision, smooth surface, and easy locking. there are many types to choose from, and it is easy to match the lighting system. access and management are more convenient.
floor design is customized according to various installation conditions, and can be easily assembled on site without welding. the use of the attic shelf system in the field of auto parts, auto parts warehouses in 4s stores, warehouses in shopping malls and supermarkets, workshops in factories, various industrial warehouses, and warehouses has increased the use rate, thereby saving intermediate logistics costs.
the overall structure of the attic shelf is assembled, without on-site welding, and the overall appearance is beautiful and generous. compared with the concrete structure or the steel structure, the shelf on the ground floor itself has the advantages of low cost and high space utilization because it supports the upper floors.
attic shelf panels are available in flat, patterned steel, punched steel, etc. to suit different requirements for fire protection, ventilation, lighting, etc. for the upper and lower floors of the cargo, forklifts, hydraulic lifting platforms, freight elevators, etc. can be selected; the transportation of goods on the same floor is usually done with small trolleys.
attic shelves are divided into medium-sized attic shelves and heavy attic shelves.
medium-sized attic shelf: the basic structure of the shelf adopts the medium-sized shelf column. the floor slab adopts special floor slab for attic shelf, and the floor slab adopts interlocking structure. erect supporting beams under the floor.
the specifications of medium-sized attic shelf columns are: 65×50×1.5mm special shelf column profiles. it is made of high-quality strip steel by kaiping, automatic mill rolling, punching and punching, and then cut according to the height specified by the customer. the upright bracket and connecting beams are made of high-quality cold plates bent and punched.
the specifications of the heavy-duty attic shelf column are 90×70×2.0mm special heavy-duty shelf column profile. it is made of high-quality strip steel by kaiping, automatic mill rolling, punching and punching, and then cut according to the height specified by the customer. the beam adopts cold-rolled p-type closed beam, and the specifications are: 60×40, 80×50, 100×50. it is a standard product specially produced for shelves in the cold bending industry. after repurchasing, the material is cut according to the customer's size, and the welding rack is connected to the special column grip and polished to form a semi-finished product.
after the production of all shelf parts, the last shot blasting machine needs to be shot blasted to remove oil, rust, and surface spray treatment. after completion, it can be packaged and shipped.
features
1. attic shelves can increase the shelf height, make full use of storage height, and make better use of storage space.
2. the special floor slabs for laying shelves on the floor of the attic shelf have the characteristics of strong lamination capacity, good integrity, uniform lamination, smooth surface, easy locking, etc. compared with the patterned steel plate or rigid grid.
3. attic shelves fully consider humanized logistics, with beautiful design and generous structure. it is easy to install and disassemble and can be flexibly designed according to the field.
4. attic shelves are suitable for storing many types of items.
structure
the overall structure of the attic shelf is assembled, without on-site welding, the overall appearance is beautiful and generous. compared with the concrete structure or the steel structure, the shelf on the ground floor itself has the advantages of low cost and high space utilization because it supports the upper floors.
attic shelf panels are available in flat, patterned steel, punched steel, etc. to suit different requirements for fire protection, ventilation, lighting, etc. for the upper and lower floors of the cargo, forklifts, hydraulic lifting platforms, freight elevators, etc. can be selected; the transportation of goods on the same floor is usually done with small trolleys.
attic shelves usually have a carrying capacity of 300kg~1000kg/m2, and the column chooses a round tube with a strong bearing capacity and a small amount of steel; the primary and secondary beams can choose the most economical and reasonable h-shaped steel and saxony in the steel structure project according to the bearing needs. the special steel platform c-shaped cold-formed beam developed by the company.
the loft-style shelf floor panel is made of special c-shaped cold-formed patterned steel plate or hollowed-out panel specially used by saxony. it adopts a buckle plate structure and is rigidly fixed to the primary and secondary beams. the entire platform structure is highly integrated, and different floor panels can be selected according to actual needs. meet the requirements of fire protection, anti-dust and anti-dropping. the lighting system can also be configured under the floor as needed.
attic shelves are widely used in the case of high warehouses, small goods, manual access, and large storage capacity, which can make full use of space and save warehouse area. according to the actual site and specific requirements, it can be designed as a single-story or multi-story loft, generally 2-3 floors. it is especially suitable for the classification and storage of auto parts, electronic devices and other enterprise series products, bearing ≤500kg/layer.
