introduce
drawer-type shelves are usually used to store heavy objects such as molds without forklifts. the top can be equipped with mobile hoist trucks (hand drawn or electric), which can realize the lifting of the mold. the bottom of the drawer plate is equipped with roller tracks. the pull, additional positioning safety device. the roller track is integrally formed with a mold, which has extremely high precision and high assembly accuracy, so the service life of the roller is greatly extended and it is effortless to pull out or push in when used. the shelf height is generally below 2.5m, except for the top layer, which can be designed and made into a drawer structure, which can easily pull out the heavy objects within 1000kg/layer, supplemented by driving or hoist, and easily realize the access operation of the goods.
according to the carrying capacity, it can be divided into two types: light weight and weight
1. the mold frame is safe and reliable: it is mainly composed of column pieces, guide grooves, drawer layers, tie rods, positioning pins, etc., which are connected by bolts, additional positioning devices can be drawn out and pushed in, which is convenient for crane or manual hoist, safe and reliable. .
2. lightweight operation: the drawer tray of the mold shelf is mainly composed of slide rails and drawer trays. the drawer tray is composed of a frame and steel plate welded by a rectangular tube and a bending piece. each slide rail is fixed up and down by two bearings, can roll freely in the guide groove, the resistance is small, and the drawer can be easily pulled out. adopt bearing combination, slide smoothly, and attached with independent hanging mold device.
3. simple structure: it is assembled from a variety of combined parts, which is convenient for transportation, installation and disassembly.
4. space saving: the mold shelf occupies a small area, has a large layer, detailed classification, and simple operation. it covers an area of only 1.8 square meters and can store dozens of medium-sized molds, effectively saving space and facilitating mold maintenance and management.
⑤ 5. according to the needs of users, we can accept mold racks with different specifications and different weights.
6. color can be customized
7. the bearing surface adopts the pattern plate, which can increase the friction to prevent the mold from slipping and other phenomena.
8. modular parts can be arbitrarily assembled in length, and can also be used as drawer tray on the beam of the cargo rack, which saves cost and has a more stable structure.
9. the height of the foot can be adjusted to overcome the uneven surface of the site.
