medium shelf view：19690

introduce

the medium-sized storage shelf adopts the structure of hanging upright columns and beams, which is convenient for disassembly and assembly. the shelf can be adjusted by 50mm, and the average load can be up to 200-600kg. the shelf span can be up to 2400mm, and the laminate can be made of steel plate or wood laminate (plywood). the shelf-type medium-sized shelves are distinguished and named according to the carrying capacity of the shelves. according to this division principle, the shelf-type medium-sized shelves have a carrying capacity in all storage shelves between the shelf-type light shelves and the shelf-type heavy shelves.

1. structural features:
1. the column of the medium-sized storage shelf is formed by rolling the cold-rolled steel sheet through a special cold-bending forming unit. the front of the column is punched with two rows of holes, and the hole distance is arranged along a straight line at a distance of 50mm. in contrast, there are a horizontal connecting pipe and an inclined connecting pipe in the middle to assemble two uprights to form upright pieces of the shelf.
2. the medium storage shelf beam adopts "p" type pipe material, commonly known as "step beam", and the height of the ladder matches the height of the laminate.
3. the steel laminates of the medium-sized storage shelves are made of cold-rolled steel plates that are bent and shaped according to the required dimensions.
4. the beams and uprights are connected and assembled into a frame, and finally the steel laminate is laid, so that a complete set of medium-sized shelves are formed.
5. after processing all the parts of the medium-sized storage shelves, all of them are processed by grinding, pickling, phosphating, fully automatic powder electrostatic spraying, drying and other processes to assemble the finished products. the surface of the finished shelf product is smooth and beautiful; the shelf layer can be adjusted up and down according to the pitch of 50mm, which is convenient for disassembly and assembly.
second, product features: it has the characteristics of easy installation, no need to put on the goods forcefully, and natural fixing. specifications and sizes can be tailored to suit your needs. can meet most of the use requirements. it is widely used for storage and display in various occasions, mainly manpower, manual handling, storage and sorting operations.

1. the column of medium a storage shelf is formed by cold-rolled steel plate by special cold bending forming unit. the cumulative error of the total length of the vertical column adjustment hole distance is not more than ± 2mm, the error of the adjacent hole distance is less than 0.02mm; the limit deviation of the size is not more than 2mm; 3. the bending error of the column is less than l/1000mm; 4. the vertical deviation of the column and the installation ground is less than l/1000mm; the front of the column is punched with double rows of holes, and the hole distance is arranged along a straight line at a distance of 50mm. it is used to hang the beam; the two columns are opposite, and there are horizontal connecting pipe and inclined connecting pipe in the middle to assemble the two columns into a shelf
　　 2. the shelf beam adopts "p" type pipe, commonly known as "step beam", and the height of the ladder matches the height of the laminate.
　　 3. shelf steel laminates are made of cold-rolled steel plates that are bent into four sides according to the required size.
　　 4. the beams and pillars are connected and assembled into a frame, and finally the steel laminate is laid, so that a complete set of medium-sized shelves are formed.
　　 5. after processing all the parts of the shelf, all the products are processed by grinding, pickling, phosphating, automatic powder electrostatic spraying, drying and other processes to assemble the finished products. the surface of the finished shelf product is smooth and beautiful; the shelf layer can be adjusted up and down according to the pitch of 50mm, which is convenient for disassembly and assembly.
the main frame and the sub-frame are assembled by uprights, beams, and laminates. an independent group has two uprights. such a shelf is called the main frame. if several groups are assembled into a column, except that the first group requires two columns, the others can share a column with the group in front of it. such a shelf is called an auxiliary shelf. this move can save space and reduce costs, the firm performance is also more stable than a single group, and the storage capacity is also greatly improved.
