introduce
cantilever shelves are an important type of shelves. cantilever shelves are suitable for storing long materials, ring materials, plates, pipes and irregular goods. the cantilever can be single-sided or double-sided. the cantilever rack has the characteristics of stable structure, good load capacity and high space utilization. the cantilever shelf column mostly adopts h-shaped steel or cold-rolled steel, the cantilever adopts square tube, cold-rolled steel or h-shaped steel, the cantilever and the column adopt the plug-in type or bolt connection type, the base and the column adopt the bolt connection type, the base adopts the cold type rolled steel or h-beam.
cantilever racks are constructed by installing cantilevers on uprights. the cantilevers can be fixed or mobile. pipes and plates are stored and used more. changzhou changtong logistics equipment co., ltd. has taken the lead in formulating and implementing the "cantilever shelf design and production specifications" in china. there is a unified specification, and cantilever shelves (non-standard) are more reasonable and safe in the design and selection of materials.
use:
cantilever rack is suitable for storing long materials, ring materials, plates, pipes and irregular goods. the cantilever can be single-sided or double-sided. the cantilever rack has the characteristics of stable structure, good load capacity and high space utilization. the cantilever shelf column mostly adopts h-shaped steel or cold-rolled steel, the cantilever adopts square tube, cold-rolled steel or h-shaped steel, the cantilever and the column adopt the plug-in type or bolt connection type, the base and the column adopt the bolt connection type, the base adopts the cold type rolled steel or h-beam. goods access is carried out by forklifts, trucks or manually. shelf height is usually within 2.5 meters (up to 6 meters if accessed by forklift), cantilever length is within 1.5 meters, and the load per arm is usually within 1000kg. such shelves are mostly used in machinery manufacturing industry and building materials supermarkets. after adding shelves, it is particularly suitable for warehouses with small space and low height. it is convenient to manage and has a wide field of view. compared with ordinary shelf shelves, the utilization rate is higher; according to the carrying capacity, it can be divided into light weight, medium weight and weight. three types.
for storage of bulky, scattered or other special products, cantilever racks are the ideal solution. cantilever racks are divided into single arm and double arm, which can efficiently store wood, pipes, strips and other similar products.
advantage:
cantilever rack is suitable for storing long materials, ring materials, plates, pipes and irregular goods. the cantilever can be single-sided or double-sided. the cantilever rack has the characteristics of stable structure, good load capacity and high space utilization. cargo access is carried out by forklifts, trucks, or manually. the height of the cantilever rack is usually within 2.0 meters (if the cargo is accessed by a forklift, it can be up to 5 meters), the length of the cantilever is within 2.0 meters, and the load per arm is usually within 800kg.
application:
cantilever shelves are mostly used in machinery manufacturing industry and building materials supermarkets. after adding shelves, it is especially suitable for warehouses with small space and low height. it is easy to manage, has a wide field of view, and has a higher utilization rate than ordinary shelves.
process:
the base of the cantilever shelf can be made of h-shaped steel or special profiles. choose h-shaped steel to choose the national standard steel according to the bearing requirements. a bolt connection eye is opened on the h-shaped steel to facilitate connection with the pillar. the bottom plate is welded to the bottom plate, and expansion bolt holes are opened on the bottom plate to facilitate the connection of the shelf to the ground with expansion bolts. to fix the shelf.
cantilever racks use special profiles as the base, weld two pieces of c-shaped steel back to back with connecting steel plates, the width of the connecting steel plate is the width of the column. after welding the two pieces of c-shaped steel, the connecting bolt holes are opened at the position of the connecting post to facilitate connection with the post. edge welding connects the bottom plate, which is convenient for the expansion bolt to connect with the ground.
the cantilever type shelf column adopts two pieces of c-shaped steel butt welded together. the c-shaped steel is made of q235 high-quality strip steel as the raw material. after being rolled into c-shaped steel by the rolling mill line, the cantilever connection control is punched out on the automatic punching machine, and the hole spacing is 140mm. a connecting steel plate is welded under the column if it is connected with the h-shaped steel. if connecting with special profiles, bolt connection holes will be opened at the connection part under the column.
