there are many practical and commonly used shelves in narrow lane shelves. narrow lane pallet shelves are one of them. the narrow lane pallet shelves have very high storage density, but they can still access all pallets in a single block. for forklifts or electronically controlled stacking cranes that require special design, narrow lanes are moved by the aisle without turning, and the storage tray for the turret or fork needs to move left and right, so the aisle is only slightly wider than the handling machinery. because the roadway shelves are higher than the general shelves, they must be installed with extremely strong rigidity and precise tolerances.
its main advantages are:
the speed of goods circulation is higher than that of ordinary shelves. the roadway forklift can work at a height of up to 14 meters, and the electronically controlled stacking crane can work even higher.
however, special forklifts or cranes are required. at the same time, it also needs other supporting machinery and the establishment of "access transfer station". the shelf not only has the function of storing pallets, but also has the function of supporting and strengthening the handling equipment. therefore, the requirements for structural strength and tolerance matching are extremely strict, and accurate design and installation must be comprehensively considered. during the operation, semi-automatic auxiliary control is used to ensure that the pallet is accurately positioned on the high-level cargo space.
in recent years, with the development of the shelf industry, the main body of the narrow aisle shelf system is a beam-type shelf system. the difference is that a "three-way stacking forklift" action rail is installed on the ground at the bottom of the shelf.
if the storage or logistics center has the following characteristics, you can consider choosing a narrow aisle shelf system:
(1) logistics efficiency requires a high level.
(2) the amount of stored goods is large, the goods enter and exit more frequently and have higher picking requirements for the goods;
(3) forklifts can use independent storage forklifts, and it is not planned to use the storage forklifts to go out to perform other tasks.
(4) the storage and logistics center urgently needs to increase the number of storage places or require a certain amount of storage;
(5) the usable net height of the warehouse is higher than 8m.
